Description
Features Technical Specification
Processor 1 processor from the following: Intel® Xeon® E-2200 product family, Intel Pentium®, Intel Core i3®, Intel Celeron®
Memory 4x DDR4 DIMM slots, supports UDIMMs, speeds up to 2666MT/s, 64GB max. supports registered ECC.
Storage controllers Internal controllers: PERC H730P, H330, HBA330 (non-RAID)
Software RAID: PERC S140
External HBAs: 12Gbps SAS HBA (non-RAID)
Boot Optimized Storage Subsystem (BOSS): 2x M.2 240GB (RAID 1 or No RAID), 1x M.2 240GB (No RAID only)
Drive bays Up to 4 x 3.5” cabled bays
Power supplies Single cabled 365W PSU
Dimensions Form factor: Mini tower server Chassis height: 360mm (14.17 in)
Chassis width: 175mm (6.89 in)
Chassis depth: 454 mm (17.9 in)
Chassis weight: 11.84 kg (26.10 lb.)
Embedded management iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC RESTful API with Redfish
OpenManage™ Software OpenManage Enterprise
OpenManage Essentials
OpenManage Power Center
OpenManage Mobile
(requires OM Enterprise or OM Essentials)
Integrations and
connections
Integrations:
Microsoft® System Center
VMware® vCenter™
BMC Truesight (available from BMC)
Red Hat Ansible
Connections:
Nagios Core & Nagios XI
Micro Focus
Operations Manager i (OMi)
IBM Tivoli Netcool/OMNIbus
Tools iDRAC Service Module
OpenManage Server Administrator
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
Dell EMC RACADM CLI
IPMI Tool
Security TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown (requires OpenManage Enterprise)
Secure Erase
I/O & Ports Networking options:
2 x 1GbE LOM
Front Ports: 1x USB 3.0, 1x iDRAC micro USB 2.0
management port
Rear Ports: 2x USB 3.0, 4x USB 2.0, VGA, serial
connector
Internal USB: 1x internal USB 3.0
4 PCIe Slots:
1×8 Gen3 (x16 connector) FH/HL
1×8 Gen3 (x8 connector) FH/HL
1×4 Gen3 (x8 connector) FH/HL
1×1 Gen3 (x1 connector) FH/HL
Supported operating
systems
Certify XenServer
Citrix® XenServer®
Microsoft Windows Server® with Hyper-V
Red Hat® Enterprise Linux
Ubuntu Server
SUSE® Linux Enterprise Server
VMware® ESXi
For specifications and interoperability details,
see Dell.com/OSsupport.
OEM-ready version
available
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
For more information, visit Dell.com/OEM.
Recommended support ProSupport Plus for critical systems or ProSupport for comprehensive hardware and software support for
your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell EMC
representative today for more information. Availability and terms of Dell EMC Services vary by region.
For more information, visit Dell.com/ServiceDescriptions.
